• Precise, easily adjustable background suppression
• Insensitive to ambient light sources
• Security against interference from other sensors installed adjacently
• Permissible ambient operating temperature -40°C...+60°C
• Fast response times, enabling fast processes

Product features
Sensing range min ... max: 30 mm ... 250 mm
Light source: LED
Type of light: Visible red light
Light spot diameter: 15 x 15 mm at 200 mm distance
Laser: Visible red light
Sensing range max.: 30 mm ... 250 mm
Relating to: Object with 90 % reflectance (referred to standard white DIN 5033)
Adjustment:: Potentiometer

Technical data
Design                                           : Rectangular
Dimensions (W x H x D)             : 12 mm x 40 mm x 22 mm
Supply voltage                                 min ... max: DC 10 ... 30 V
Ripple                                            : ≤ 5 Vpp
Power consumption                   : ≤ 40 mA
Switching output                          : PNP antivalent
Output current                                 max.: ≤ 100 mA
Response time                            : ≤ 333 µs
Switching frequency                    : 1,500 Hz
Connection type                           : Cable, 2 m
Number of cores                          : 4
Conductor size                             : 0.14 mm²
