Model

LX2-13W

Light source

Type

Invisible infrared semiconductor laser

Wavelength

780 nm

Output

0.2mW (IEC),
0.1mW (FDA)

Laser
Class

FDA (CDRH) 21CFR
Part 1040.10

Class I

Pulse duration

30 μs

Laser
Class

DIN EN 60825-1

Class 1

IEC/EN 60825-1

Detecting distance

0 to 300 mm

Detecting area
(width x thickness)

30 x 1 mm
(118.1 x 39.4 Mil)

Repeatability ^*1

10 μm (10 Mil)

Smallest detectable object

Opaque object
with a 0.2 mm
(7.9 Mil) dia.

Ambient light

Incandescent lamp: 10,000 lux
Fluorescent lamp: 10,000 lux

Ambient temperature

0 to +50°C (32 to 122°F), No condensation

Relative humidity

35 to 85%, No condensation

Vibration

10 to 55 Hz, 1.5 mm double amplitude in X, Y, and Z directions, 2 hours.

Material (housing)

Zinc die-cast

Weight
(including 1.8-m cable)

Transmitter:
Approx. 260 g
Receiver:
Approx. 160 g
