| Model : LV-21A |
| Main unit / Expansion unit : Main Unit |
| Response speed : FINE: 80 μs/ TURBO: 500 μs/ SUPER TURBO: 4 ms |
| Control output : NPN open-collector x 2 channels, 40 VDC max., max. 100 mA, residual voltage (1.0 V max.) |
| Protection circuit : Reverse polarity protection, overcurrent protection, surge absorption |
| Expansion of units : Up to 7 additional expansion units can be installed (8 units including the main unit), |
| Number of interference preventive units : FINE：None、TURBO：2 units、SUPER：4 units |
| Power supply voltage : 12 to 24 VDC ripple (P-P) 10% max. |
| Power consumption : 1.5 W max. (125 mA max. for 12 V, 62.5 mA max. for 24 V) |
| Ambient temperature used : -10 to +55˚C (14 to 131˚F), No condensation |
| Ambient humidity used : 35% to 85% RH, No condensation |
| Material : Main body, cover: Polycarbonate |
| Weight : Approx. 120 g |
LV-21A Keyence Digital Laser Sensor , Amplifier Unit, Main Unit , NPN
Harga :
CALL
Merk :
Keyence
Pengiriman :
3 hari sejak pembayaran
Lokasi :
Jawa Barat - Bekasi
Dilihat :
390 Kali
Update Terakhir :
09-09-2014 01:47
Dapatkan Spesifikasi Harga LV-21A Keyence Digital Laser Sensor , Amplifier Unit, Main Unit , NPN Produk Terbaik dari
CV. Karunia Jaya Abadi Omron, Sick, Thermocouple, Keyence, Sun-X, Grainger,
