At a glance
• Tough, metal housing
• Manual switching threshold adjustment with optical adjustment indicator
• Green or white LED technology
• Models with analog output
• Switching frequency of 10 kHz
• Various sensing distances and light spot directions
• M12 plug can be rotated 90°

Your benefits
• All standard print marks and contrasts are detected
• Reliable operation, even with jittering webs and high-gloss materials
• High positioning accuracy improves packaging quality
Various sensing distances, light spot directions and light emissions make
individual configuration and simple integration into the production process
possible

Features
Dimensions (L x W x H): 80 mm x 30.4 mm x 53 mm
Sensing distance : : 10 mm
Sensing distance tolerance: ± 3 mm
Light source : LED green
Light emission: Long and short side of housing, exchangeable
Light spot size: 1.2 mm x 4.2 mm
Light spot direction :  Vertical
Adjustment: Manual adjustment, potentiometer
Output function: Light/dark switching

Mechanics/electronics
Supply voltage : DC 10 V ... 30 V
Ripple :  ≤ 5 Vpp
Power consumption :  < 80 mA
Switching frequency :  10 kHz
Response time :  50 µs
Output type: PNP
