Model |
FU-77V |
|||
|
Detection system |
Thrubeam |
|||
|
Optical axis diameter (mm) |
Object with a diameter of 1.13 |
|||
|
Standard detection object (mm) |
||||
|
Design |
Straight |
|||
|
Size (mm) |
M4 |
|||
|
Cable length |
2 m free-cut |
|||
|
Fiber diameter |
2.2 |
|||
|
Operating ambient temperature |
-40 to +50°C |
|||
|
Fiber allowable bend radius (mm inch) |
R0.5 Tough-Flex |
|||
|
Detection distance (mm inch)when the FS-N10 Series is used |
MEGA |
3600 |
||
|
MEGA |
ULTRA |
3000 |
||
|
SUPER |
1800 |
|||
|
TURBO |
1300 |
|||
|
FINE |
880 |
|||
|
HIGH SPEED |
430 |
|||
|
When using the FS-V30 Series |
When APC is on |
MEGA |
1300 |
|
|
ULTRA |
1100 |
|||
|
SUPER |
600 |
|||
|
TURBO |
460 |
|||
|
FINE |
230 |
|||
|
HIGH SPEED |
140 |
|||
|
When APC is off |
MEGA |
1700 |
||
|
ULTRA |
1300 |
|||
|
SUPER |
750 |
|||
|
TURBO |
600 |
|||
|
FINE |
300 |
|||
|
HIGH SPEED |
200 |
|||
|
Minimum detectable object (mm)*1 |
Object with a diameter of 0.005 |
|||
|
Weight |
Approx. 25 g |
|||
|
*1 The minimum detectable object is the value when the detecting distance and sensitivity have been set to their optimal state. |
||||
FU-77V Keyence Transmissive Fiber Unit
Harga :
CALL
Merk :
Keyence
Pengiriman :
3 hari sejak pembayaran
Lokasi :
Jawa Barat - Bekasi
Dilihat :
334 Kali
Update Terakhir :
09-09-2014 01:45
Dapatkan Spesifikasi Harga FU-77V Keyence Transmissive Fiber Unit Produk Terbaik dari
CV. Karunia Jaya Abadi Omron, Sick, Thermocouple, Keyence, Sun-X, Grainger,
