| Model : FS2-60 |
| Type : Trimmer , Long Detecting Distance |
| Light source : Red LED |
| Sensitivity adjustment : 8-turn trimmer |
| Response time : 250 μs |
| Operation mode : LIGHT-ON/DARK-ON (switch-selectable) |
| Display indicator : - Output: Red LED |
| - Stable operation: Green LED |
| Timer mode : ON-delay: 40 ms/OFF-delay: 40 ms/Timer OFF (switch-selectable) |
| External calibration input signal : ----- |
| Buzzer mode : Buzzer ON when control output turns ON/Buzzer ON when alarm output turns ON/Buzzer OFF (switch-selectable) |
| Control output : NPN open-collector 100 mA max. (40 V max.), Residual voltage 1 V max. |
| Stability output : NPN open-collector 50 mA max. (40 V max.), Residual voltage 1 V max. |
| Protection circuit : Reversed polarity protection, Overcurrent protection, Surge absorber |
| Power supply : 12 to 24 VDC ±10%, Ripple (P-P): 10% max. |
| Current consumption : 35 mA max |
| Ambient light : Incandescent lamp: 10,000 lux max., Sunlight: 20,000 lux max. |
| Housing : Polycarbonate |
FS2-60 Keyence Fiber Amplifier , Cable type , NPN
Harga :
CALL
Merk :
Keyence
Pengiriman :
3 hari sejak pembayaran
Lokasi :
Jawa Barat - Bekasi
Dilihat :
352 Kali
Update Terakhir :
09-09-2014 01:46
Dapatkan Spesifikasi Harga FS2-60 Keyence Fiber Amplifier , Cable type , NPN Produk Terbaik dari
CV. Karunia Jaya Abadi Omron, Sick, Thermocouple, Keyence, Sun-X, Grainger,
