| Model : FS-V31 |
| Type : 1-output with cable |
| Main unit/Expansion unit : Main unit |
| Control output : 1 output |
| Monitor output (1 to 5 V) : NA |
| External input : NA |
| Connector : ---- |
| Light source : Red, 4-element LED (Wavelength: 640 nm) |
| Response time : 33 μs (HIGH SPEED)/250 μs (FINE)/500 μs (TURBO)/ |
| : 1 ms (SUPER TURBO)/4 ms (ULTRA TURBO)/16 ms (MEGA TURBO) |
| Output selection : LIGHT-ON/DARK-ON (switch-selectable) |
| Display indicator : Operation indicator: Red LED/Dual digital monitor: Dual 7-segment display, Preset Value (4-digit green LED indicator) and |
| : Current Value (4-digit red LED indicator) illuminated together. Current Value range: 0 to 64,512; Excess gain: 0P to 999P, |
| : Hold function: Possible to display both peak and bottom hold values, Selectable from 5 variations. |
| : Bar LED monitor: Excess gain displayed (85% to 115% in 7 steps), Scaling display. |
| Detection mode : Light intensity (area detection possible, automatic sensitivity-tracking function provided) |
| Timer function : OFF-delay timer/ON-delay timer/One-shot timer/ON-delay timer + OFF-delay timer |
| / ON-delay timer + One-shot timer, selectable |
| : Timer duration selectable: 0.1 ms to 9,999 ms, Maximum error against the setting value: ±10% max. |
| Control output : NPN open-collector 24 V, 100 mA max.*1 (main unit only)/20 mA max. (when the |
| expansion unit(s) is connected), Residual voltage: 1 V max. |
| External inputy : Input time: 2 ms (ON)/20 ms (OFF) min. |
| Unit expansion : Up to 16 expansion units can be connected (a total of 17 units). Note that the 2-output type should be counted as two units |
| Number of interference prevention units : Normal operation : HIGHSPEED：0 FINE：4 TURBO/SUPER/ULTRA/MEGA：8 |
| Power supply : 12 to 24 VDC (±10%), ripple (p-p): 10% max., Class 2 |
| Current consumption : Normal: 710 mW max. (Using 24 V, 29 mA max., using 12 V, 40 mA max.)/ |
| Power saving: 540 mW max. (Using 24 V, 22 mA max., using 12 V, 28 mA max.) |
| Ambient illumination : Incandescent lamp: 20,000 lux max., Sunlight: 30,000 lux max. |
| Relative humidity : -10 to +55°C (14 to 131°F), No condensation |
| Ambient temperature : 35 to 85%, No condensation |
| Shock resistance : 500 m/s2 in X, Y, and Z directions, 3 times respectively |
| Vibration resistance : 10 to 55 Hz, double amplitude: 1.5 mm 0.06", 2 hours each in the X, Y and Z axis |
| Housing : Polycarbonate |
| Size : 30.3 mm (H) x 9.8 mm (W) x 71.8 mm (D) 1.19" (H) x 0.39" (W) x 2.83" (D |
| Weight : Approx. 80 g |
FS-V31 Digital Fiber Sensor Amplifier NPN
Harga :
CALL
Merk :
Keyence
Pengiriman :
3 hari sejak pembayaran
Lokasi :
Jawa Barat - Bekasi
Dilihat :
368 Kali
Update Terakhir :
09-09-2014 01:49
Dapatkan Spesifikasi Harga FS-V31 Digital Fiber Sensor Amplifier NPN Produk Terbaik dari
CV. Karunia Jaya Abadi Omron, Sick, Thermocouple, Keyence, Sun-X, Grainger,
