FS-M2 Keyence , Fiber Amplifier, Cable Type, Expansion Unit, NPN
Pengiriman :
3 hari sejak pembayaran
Lokasi :
Jawa Barat - Bekasi
Update Terakhir :
09-09-2014 01:45
Dapatkan Spesifikasi Harga
FS-M2 Keyence , Fiber Amplifier, Cable Type, Expansion Unit, NPN Produk Terbaik dari
CV. Karunia Jaya Abadi Omron, Sick, Thermocouple, Keyence, Sun-X, Grainger,
Detail Produk
| Model : FS-M2 |
| Type : 1-line Expansion unit |
| Light source : Red LED |
| Sensitivity adjustment/Mode selection : 8-turn trimmer (with indicator), FINE/TURBO (switch-selectable) |
| Response time : 250 μs (FINE)/500 μs (TURBO) |
| Operation mode : LIGHT-ON/DARK-ON (switch-selectable) |
| Display indicator : - Output indicator: Red LED, |
| - Stable operation indicator: Green LED |
| Timer function : ON-delay: 40 ms/ OFF-delay: 40 ms/ Timer OFF (switch-selectable) |
| External calibration input signal : ------------ |
| Control output : NPN open-collector 100 mA max. (40 VDC max.), Residual voltage: 1 V max. |
| Stability output : NPN open-collector 50 mA max. (40 VDC max.), Residual voltage: 1 V max. |
| Protection circuit : Reversed polarity protection, over-current protection,surge absorber |
| No. of expansion units : Up to 16 expansion units can be connected (a total of 17 units) |
| Mutual interference suppression : FINE : 4, TURBO/SUPER: 8 |
| Power supply : 12 to 24 VDC (±10%), ripple (p-p): 10% max |
| Current consumption : 35 mA max. |
| Housing : Polycarbonate |
